Item NO.:
MSL-AD-L13-X07800BENPayment:
T/T before productionProduct Origin:
Fujian,ChinaColor:
BlackShipping Port:
Xiamen|
Features： |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Technical Parameters： |
|
|
Specification parameter |
|
|
Appearance dimensions (length × width × thickness) |
Front panel: 364.5*82*73.1mm
Rear panel: 364.5*82*72.3mm
|
|
Color |
Black(Powder spray) |
|
Shell material |
Aluminum alloy + tempered glass |
|
Adapt to Lock Body |
6068 standard lock body/overlord lock body |
|
Door Lock Cylinder |
Direct plug-in Class C lock cylinder (true mortise) |
|
Input Power |
4 AA dry batteries |
|
Emergency Power Outlet |
Type-C（5V） |
|
Average Operating Power Consumption |
20mA |
|
Standby Power Consumption |
50μA |
|
Operating Temperature |
-25℃ ~ +70℃ |
|
Storage Temperature |
-25℃ ~ +80℃ |
|
Working Humidity |
0~93%±3%RH, no condensation |
|
Flammability Rating |
GA 374-2019 standard |
|
Protection Level |
IP52 |
|
Applicable Door Thickness |
Standard 50mm~100mm (if you need 45mm~130mm, please note when ordering) |
|
Applicable Door Types |
Wooden doors, security doors |
|
Door Opening Direction |
Supports left inner/outer door opening, right inner/outer door opening |
|
Hardware & interface |
|
|
Fingerprint reader |
Semiconductor |
|
Number Key |
3×4 numeric keypad |
|
Doorbell Button |
*Key reuse |
|
Mute Key |
press and hold the 0 key for 2 seconds to enter silent mode, sleep or enter the management background to exit automatic silent mode |
|
Reset Button |
Supported (rear panel) |
|
Audio output |
Front speaker, rear speaker |
|
Fingerprint Breathing Light |
Supported |
|
Button Indicator Light |
Supported |
|
Communication parameter |
|
|
Networking form |
Off the Internet |
